What you will need

What you will get

  • Knowledge of nominal content of the Duckiebot DB21-J4 box.

What’s in the Duckiebot (DB21-J4) Box?#

What should you expect to find inside a Duckiedrone (DD24) box, and what is each component?

First things first: here is how a Duckiedrone box looks like:

Duckiebot box

Fig. 9 The yellow Duckiebot box.#

And is here an incomplete representation of the components in the box. Continue scrolling for the complete list.

Duckiebot box content - selected components

Fig. 10 What’s inside the Duckiebot DB21-J4 box (selected components).#

List of components (DB21J4(v2))#

This list is representative. Details vary between production rounds.

We are always striving to improve, so minor details - e.g. the number and type of nuts and screws - can change between different manufacturing rounds of the same Duckiebot model. Most notably, all Duckiebots labeled as DB21J4(v3) (post September 2025) will replace chassis-related metal screws with nylon ones, and improve the omnidirectional wheel design, as well as presenting minor chassis design modification to accomodate for more Jetson Nano development kits.

Number

Component

1

Bottom deck

2

Lower lateral supports

1

Middle deck

1

Upper-left lateral support

1

Upper-right lateral support

1

Back support

1

Top deck

1

Back pattern plate

2

Motor mounts

1

Camera mount

1

Front bumper (FB) PCB

1

Back bumper (BB) PCB

1

Omni-wheel

2

Front wheels

2

DC Motors with Encoders

1

Jetson Nano camera

1

Camera cable

1

Inertial Measurement Unit (IMU)

1

Time of flight (ToF) sensor

1

Jetson Nano 2GB (JN2), Jetson Nano 4GB (JN4) or No Jetson (variants)

1

Duckietown Hut v 3.15

1

64GB Class 10 U3 micro SD card

1

Duckiebattery

1

Wi-Fi dongle

1

Screen

1

Shutdown button

1

DC fan

1

FCC label sticker

1

Cross screwdriver

1

Camera calibration pattern

1

Micro SD to USB adaptor

1

Back pattern sticker

3

Metal stand-off M2.5x18+6mm M-F

3

Metal hexagon stand-off M3 25mm F-F

2

Spacer M6x12x1.5

4

Nylon screw M2x8

14

Nylon screw M2.5x12

2

Round head tapping screws metal (3x20)

4

Metal screw M3x30

30

Metal screw M3x12

30

Metal nut M3

16

Nylon nut M2.5

4

Nylon nut M2

1

Jetson to Battery cable

1

Battery to HUT(Ext5V) power cable

1

HUT to Battery charging cable

1

HUT to BB cable

2

Motor to HUT cables

1

FB to ToF cable

3

HUT to FB, IMU cable

1

Screen to HUT cable

1

Button to HUT cable

2

Duckies

1

Instructions card

2

Duckietown Stickers
